Gear oil pump is a pair of gears and pump cylinders that mesh with each other to separate the suction cavity from the discharge cavity. Gear oil pumps can produce certain functions and performances in different aspects, and show good contributions in actual production. They can penetrate into different fields. When the gear rotates, the suction cavity side gear teeth are separated from each other. The volume gradually increases, the pressure decreases, and the liquid enters between the teeth under the action of the pressure difference. As the gear rotates, the liquid between the teeth is brought to the discharge chamber. At this time, the volume between the teeth of the gear teeth on the discharge cavity side gradually decreases, and the liquid is discharged.
Gear oil pumps are produced according to different standards and methods in actual production, and can produce important functions and performances for you in actual work, and realize good effects and values in the field. Gear oil pumps are suitable for transporting lubricating liquids that do not contain solid particles, are non-corrosive, and have a large viscosity range. The flow rate of the pump can reach 300 m3/h, and the pressure can reach 3×107 Pa. It is usually used as a hydraulic pump and conveying various oil products. The gear oil pump has simple and compact structure, easy manufacture, convenient maintenance, self-priming capability, but large flow and pressure pulsation and high noise. The gear oil pump must be equipped with a safety valve to prevent damage to the pump or prime mover due to some reasons, such as blockage of the discharge pipe, which causes the outlet pressure of the pump to exceed the allowable value.
