High Temperature Resistant Centrifugal Pump Installer
Home > Products > Gear Oil Pumps > 1 inch Gear Oil Pumps >
new products
latest news

Differences between lobe pumps

There are many differences between lobe pumps and gear pumps: 1. Volume: Due to its compact design, the lobe lobe pump requires a small footprint. No additional space is required to service the pump. Standard flange, diameter can be adjuste...

1 Inch Gear Oil Pump KCB 55 1 KCB 55 gear oil pump kcb 83.3 gear oil pump

1 Inch Gear Oil Pump - KCB 55

  • item no.:

    KCB55

  • lead time:

    Customer Date

  • product orgin:

    china saiken pumps

  • shipping port:

    Tianjin China

  • payment:

    L/C Or T/T

  • color:

    Customer Color
contact now
  • description
KCB 55 (2CY-3.3/0.33) Gear oil Pump & 1 Inch Gear Oil Pump Specifications：

     Model        Capacity
        (L/min)		     Pressure
        (Bar)		     Speed
     (rpm)		      Caliber
      (inch)		     Power
     (kw)		         Efficiency
     KCB 55    55 (14.5 gpm)         3.3      1420         1”       1.5           59%
  Packing        details                  290mm X 245mm X 320mm, with export standard wooden case



Application:
KCB gear pumps applies to transfer non-corrosive lubricating-oil or equivalent liquid without solid particle and fibre at temperature below 300℃ and with the viscosity of 5×10-6～1.5×10-3m2/S(5-1500cSt), such as diesel oil, crude oil, engine oil, hydraulic oil etc. If it is coupled with copper gear and ex-proof motor, it is suitable for gasoline, benzene transfer. It also fit for drink, milk, honey, vegetable oil transfer if coupled with stainless steel material.

Feature:
This pump is coupled with pressure relief valve. There are cast iron, cast steel and 304/316/316L stainless steel pump body for option. The seal can be oil seal, packing seal or mechanical seal at customer’s demand.

Model Capacity Q Speed
r/min		 Exhaust
Pressure
Mpa		 (NPSH)r
m		 Efficiency
η % 		 Motor
m3/h L/min Power
kw		 Model
KCB-18.3 1.1 18.3 1400 1.45 5 44 1.5 Y90L-4
2CY-1.1/1.45
KCB-33.3 2 33.3 1420 1.45 5 44 2.2 Y100L1-4
2CY-2/1.45
KCB-55 3.3 55 1400 0.33 7 41 1.5 Y90L-4
2CY-3.3/0.33
KCB-83.3 5 83.3 1420 0.33 7 43 2.2 Y100L1-4
2CY-5/0.33
KCB-135 8 135 940 0.33 5 46 2.2 Y112M-6
2CY-8/0.33
KCB-200 12 200 1440 0.33 5 46 4 Y112M-4
2CY-12/0.33
KCB-300 18 300 960 0.36 5 42 5.5 Y132M2-6
2CY-18/0.36
KCB-483.3 29 483.3 1440 0.36 5.5 42 11 Y160M-4
2CY-29/0.36
KCB-633 38 633 970 0.28 6 43 11 Y160L-6
2CY-38/0.28
KCB-960 58 960 1470 0.28 6.5 43 18.5 Y180M-4
2CY-58/0.28
KCB-1200 72 1200 740 0.6 7 43 37 Y280S-8
KCB-1600 95 1600 980 45 Y280S-6
KCB-1800 112 1800 740 0.6 7.5 43 55 Y315S-8
KCB-2500 150 2500 985 75 Y315S-6
KCB-2850 170 2850 740 0.6 8 44 90 Y315L1-8
KCB-3800 230 3800 989 110 Y315L1-6
KCB-4100 245 4100 743 0.6 8 44 132 Y355M1-8
KCB-5400 325 5400 989 160 Y355M1-6
KCB-5600 330 5600 744 0.6 8 44 160 Y355M2-8
KCB-7600 460 7600 989 200 Y355M3-6
KCB-7000 420 7000 744 0.6 8 44 185 Y355L1-8
KCB-9600 570 9600 989 250 Y355L2-6




tags :
Request a free quote

related products
  • GC13 pulley driven pump for hig

    GC-13 Gear Oil Pump with belt pulley made of Cast Iron,GC Series Gear Pump Suitable for Water Oil Various Liquids Applications,Application Kerosene,Light oil,Machine oil,Heavy oil ,Water. ...

  • 1 inch GC pulley gear pump manu

    GC-25 1" Gear Oil Pump with belt pulley made of Cast Iron,GC Series Gear Pump Suitable for Water Oil Various Liquids Applications,Application Kerosene,Light oil,Machine oil,Heavy oil ,Water. ...

  • 1 Inch Gear Oil Pump - KCB 55

    KCB gear oil pump applies to transfer non-corrosive lubricating-oil or equivalent liquid without solid particle,diesel oil,crude oil,engine oil,hydraulic oil etc.If it is coupled with copper gear and ex-proof motor,it is suitable for gasoline, benzene...
