Introduction of mechanical operation test of gear oil pump

2020-07-13

Gear oil pump performance curve and data include: total head, efficiency, shaft power and speed and correction calculation, make H-Q, P-Q, curve vibration and temperature rise; noise measurement; NPSH test;

    Mechanical operation test of gear oil pump: After the performance test, a continuous mechanical operation test should be conducted under the design conditions to check the mechanical operation. The inspection time is usually one hour. When the test equipment cannot be the pump running at the design speed, the test speed It can be different from the design speed.If the necessary disassembly is required for the change range of the rated speed, the initial test results are invalid and the final test shall prevail.

    The concept of the  SS gear oil pump is very simple, that is, its most basic form is that two gears of the same size are meshed with each other in a tightly matched housing. The inside of this housing is similar to an "8" shape, and the two gears are installed inside. , The outer diameter and both sides of the gear are closely matched with the shell. The material from the extruder enters the middle of the two gears at the suction port, and fills this space. As the teeth rotate, they move along the shell, and finally the two teeth Discharge when engaged.

KCB Gear Oil Pump
