High Temperature Resistant Centrifugal Pump Installer

Hot oil pumps & thermal oil circulation pumps

  • item no.:

    BRY65-50-160
  • lead time:

    Customer Date
  • product orgin:

  • shipping port:

    Tianjin China
  • payment:

    L/C Or T/T
  • color:

    Customer Color
  • description
Hot oil pumps & thermal oil pumps,This centrifugal pumps mainly use for thermal oil circulation. structure can be centrifugal hot oil pump and gear hot oil pump. Thermal Oil Pump Manufacturer & supplier best price from china saiken pumps

RY Hot Oil Pump is widely applied in the heating system with heat transfer medium in many industrial fields, such as petroleum, chemical industry, rubber, plastics, pharmacy, textiles ,printing and dyeing, foodstuff industry, road construction. It is an ideal circulation pump for hot oil and mainly used in transferring weak corrosion and high temperature liquid, but without solid grains, and whose temperature is below 370 ℃.

Thermal oil pumps specification:

Size: DN20-250mm
Capacity: 4.5-1300m3/h
Head: 15-130m
Working temperature: ≤400℃
Material: Cast iron, Cast steel, SS304, SS316, SS316Ti, SS316L, CD4MCu, Titanium, Titanium Alloy, Hastelloy Alloy etc

Hot oil pumps Design Features:

1. RY hot oil pump is the second generation of oil pump product developed on the basis of digesting foreign oil pumps. Its basic structure is single-stage single-suction cantilever let support, which has an axial suction inlet and a centrally vertical outlet. It is mounted on the base along with the motor.
2. RY thermal oil pump adopts a double-end ball bearing support with the front end using the lubricating oil while the back end using teh grease as the lubricant, and an oil conduit lying in between for always keeping an eye on the sealing and the recovery of conduction oil.
3. RY hot oil pump adopts the self-heating and abstraction of heat structure instead of the traditional water cooling structure, thus featured by a simple and space-effective, fewer operating costs, good peformance and reliable operation.
4. RY hot oil pump conbines packing seal and mechanical seal, the former has a good adaptability for the thermal state due to useing packing with resistance to high temperature while the latter ensures the seal performance under high temperature as it adopts the hard alloy with strong mechanical strength and wear resistance.
5. RY hot oil pump adpots the third generation of PTFE for the lip seal, thus getting great performance in the seal performance,  the rubber seal, and extremely strong resistance to corrosion.
If you have any queries or hot oil pump specifications, please email me: annie@saikenpumps.com / Whatsapp : +8617731766260
