The inner ring type NYP high-viscosity gear pump has always transported viscous liquids, such as lubricating oil and combustion oil. It is not suitable to transport liquids with low viscosity (such as water and gasoline), and it is not suitable to transport liquids containing particulate impurities (affecting the pump Service life), can be used as lubrication system oil pump and hydraulic system oil pump, widely used in engines, steam turbines, centrifugal compressors, machine tools and other equipment. The inner ring type NYP high viscosity gear pump has high process requirements, and it is not easy to obtain accurate matching. The following introduces several unique inner ring NYP high viscosity gear pump products.
Inner ring type high viscosity series straight tooth conjugate inner mesh inner ring type NYP high viscosity gear pump: It is a novel design with international advanced hydraulic power components, it has a simple structure, low noise, long life and low pollution sensitivity Etc. Widely used in hydraulic systems of various machinery such as mining machinery, engineering machinery, plastic machinery, metallurgical machinery, power station auxiliary machinery, petrochemical machinery, food packaging machinery, precision machine tools, general machine tools, etc. Technical innovation features:
1. The principle of straight tooth conjugate meshing is adopted, the gear tooth shape adopts straight line, and the best tooth shape angle is established, and the tooth shape of the ring gear adopts linear conjugate line, so that there is no trapped oil area after meshing, so as to achieve stable and accurate work , High, volumetric efficiency improvement, low noise ideal effect.
2. Two-stage pressurization: The inner ring type NYP high-viscosity gear pump adopts a two-stage pressurization structure, which does not increase the spindle load, improves the output pressure of the pump, and extends the service life of the pump.
3. Liquid dynamic and static pressure bearing: The inner ring type NYP high viscosity gear pump has no axial load, the axial gap between the ring gear and the pump casing is very small, and it is filled with oil during the formation of a dynamic and static pressure bearing.
4. Modular design: The main parts of the inner ring type NYP high viscosity gear pump are highly standardized, which is suitable for advanced modular design.
5. Special tooth shape: the outer tooth outline of the inner ring type NYP high viscosity gear pump is a straight line, and the inner ring gear is a straight line conjugate line.
