High Temperature Resistant Centrifugal Pump Installer
Home > Products > Magnetic Drive Pumps > Polypropylene & PVDF Magnetic Drive Pump >
new products
latest news

Differences between lobe pumps

There are many differences between lobe pumps and gear pumps: 1. Volume: Due to its compact design, the lobe lobe pump requires a small footprint. No additional space is required to service the pump. Standard flange, diameter can be adjuste...

0.5HP-Commercial-Acid-Proof-Sewage-Pumps-Magnetic-Driven-Pump 0.5HP-Commercial-Acid-Proof-Sewage-Pumps-Magnetic-Driven-Pump 0.5HP-Commercial-Acid-Proof-Sewage-Pumps-Magnetic-Driven-Pump 0.5HP-Commercial-Acid-Proof-Sewage-Pumps-Magnetic-Driven-Pump

0.5HP Commercial Acid Proof Sewage Pumps Magnetic Driven Pump

  • item no.:

  • lead time:

    Customer Date

  • product orgin:

  • shipping port:

    Tianjin China

  • payment:

    L/C Or T/T

  • color:

    Customer Color
contact now
  • description
0.5HP Commercial Acid Proof Sewage Pumps Magnetic Driven Pump


Product Characterist

• use magnetic drive, no shaft seal design, pump body fully sealed.
• use FRPP and PVDF material injection molding, suitable for most chemical acid base liquid delivery.
• impeller and magnet integrated injection molding, in high-speed operation and high temperature is not easy to damage.
• this series of pumps because of its innovative design of resistance to idling, the magnetic pump running without water for a long time without damage, improve product durability. Pump bearings are made of silicon carbide, ceramic and titanium materials, which can meet the needs of different workplaces.


purchase notes

1. suitable for all kinds of acid and alkali liquid cooling, spraying and washing equipment, waste gas tower, carving machine, waste water treatment and so on
2. controllable operation, never by air instead of damage
3. dry seal design, can protect the motor to prevent acid gas into the damaged bearing
4. it is suitable for the cyclic transportation of electroless nickel, electroless copper and various s pecial electroplating liquid
5.explosion-proof motor can be used according to the environment


Specification

Type In-Outlet(Inch) Power 50HZ 60HZ Weight(kg)
Max Head(m) Max Flow(I/min) Max Head(m) Max Flow(I/min)
CSM-400 1-1/2" 1/2HP 9.5 240 10 240 16
CSM-401 1-1/2" 1HP 12 340 14.5 300 23
CSM-402 2"*1/2" 2HP 23 480 24.5 420 33
CSM-403 2"*1/2" 3HP 25 550 27 520 37
CSM-405 2"*1/2" 5HP 30 550 32 560 52
CSM-505 2-1/2"*2" 5HP 28 680 30 750 55
